Swan Manufacturing

Slip Form Paver Machine

The Slip Form Road Paver Machine by SWAN MANUFACTURING is a heavy-duty, high-performance concrete paving solution designed for continuous, uniform, and high-quality concrete road construction. The Slip Form Road Paver Machine is engineered for precision paving of rigid pavements without the use of side forms, ensuring faster execution, superior surface finish, and long service life.

The Slip Form Road Paver Machine is widely used for highways, expressways, airport runways, industrial roads, and urban infrastructure projects. Built with a robust steel structure, advanced hydraulic system, and intelligent control mechanisms, the Slip Form Road Paver Machine delivers consistent results even in demanding site conditions.

Parameter Specification
Machine Name Slip Form Road Paver Machine
Machine Type Concrete Slip Form Road Paver Machine
Paving Width 3.5 m to 9.0 m (Customizable)
Paving Thickness 150 mm to 450 mm
Concrete Slump Range 30 mm – 80 mm
Paving Speed 0.5 – 3.0 meters/min
Concrete Spreading System Auger / Plough type
Vibration System High-frequency hydraulic vibrators
Levelling System Hydraulic screed with finishing pan
Grade Control Automatic sensor-based grade & slope control
Drive System Hydrostatic crawler track drive
Power Source Diesel engine
Hydraulic System Heavy-duty closed-loop hydraulics
Chassis & Frame Heavy-duty welded structural steel
Surface Finish Smooth / Textured (as required)
Mobility Self-propelled crawler mounted
Applications Highways, Expressways, Airport Runways, Industrial Roads
Customization Available as per project requirement

Key Features

  • Continuous concrete paving without fixed side forms
  • High-strength fabricated steel chassis
  • Precise grade and slope control system
  • Heavy-duty vibration system
  • Low maintenance and operator-friendly design
  • Applications

  • National & State Highways
  • Expressways and rigid pavements
  • Airport runways and taxiways
  • Industrial and logistics roads
  • Swan Standard Scope of Supply

  • Main paver chassis with paving kit
  • Hydraulic power pack / engine unit
  • Operator control console
  • Sensor mounting provisions
  • Basic tool kit & operation manual
